Camera Image Sensor 1/2.7” 8Megapixel progressive CMOS Max. Resolution 3840 (H) × 2160 (V) ROM 128 MB RAM 256 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.009 Lux@F2.0 S/N Ratio >56 dB Illumination Distance 30 m (98.43 ft) Illuminator On/Off Control Auto/Manual Illuminator Number 1 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° Lens Lens Type Fixed-focal Mount Type M12 Focal Length 2.8 mm3.6 mm Max. Aperture F2.0 F2.0 Field of View 2.8 mm: Horizontal 105° × Vertical 56° × Diagonal 125° 3.6 mm: Horizontal 87° × Vertical 47° × Diagonal 104° Iris Type Fixed Close Focus Distance 2.8 mm: 1.0 m (3.3 ft)3.6 mm: 1.9 m (6.2 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 74.7 m(245.1 ft) 29.9 m(98.1 ft) 14.9 m(48.9 ft) 7.5 m(24.6 ft) 3.6 mm 106.7 m(350.1 ft) 42.7 m(140.1 ft) 21.3 m(69.6 ft) 10.7 m(35.1 ft) Smart event IVS Tripwire; intrusion Video Video Compression H.265; H.264; H.264B; MJPEG (only supported by the sub stream) Smart Codec Smart H.265+/ Smart H.264+ Video Frame Rate Main stream: 3840 × 2160 (1 fps–15 fps) 2688 × 1520 (1 fps–25/30 fps) Sub stream: 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps) Stream Capability 2 streams Resolution 3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps Day/Night Auto(ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest(RoI) Yes (4 areas) Smart Illumination Yes Image Rotation 0°/90°/180°/270° (Supports 90°/270° with 3840 × 2160 resolution and lower.)
Основные атрибуты | |
---|---|
Производитель | Dahua |
Пользовательские характеристики | |
Бренд | Dahua |
Дальность ИК-подсветки | 30 м |
исполнение | Уличное |
Материал корпуса | Металл |
Наличие MicroSD | Да |
Наличие микрофона | Нет |
Объектив | 2.8 мм |
Рабочая температура | -40°C до +60°C |
Разрешение | 8 мп |
Тип объектива | Фиксированный |
- Цена: 72 000 ₸
