Technical Specification Mode ASI1201E ASI1201E-D System Main Processor 32 Bit Input/Output Ports Input Door sensor x 1, Exit button x 1 Output Relay x 1 (Door lock,) Reader Reader x 1 Card Read Read Format 13.56MHz 125KHz Read Range 1cm–2cm (max.) Response Time <0.1s Capacity Cardholders 30,000 Events 60,000 Function User Management General, VIP, Guest, Patrol, Black list, Duress Alarm Function Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm Period Setting Support 128 groups of schedule, 128 groups of periods and 128 groups of holiday periods Interface To PC RJ45(10/100M) To Reader Wiegand26/34, RS485 Genreal Ingress Protection IP66 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) RTC Yes Beep Tone Buzzer Keyboard Sensitive touch keypad with blue backlight Power Supply DC 9-15V/100mA Operating Temperature -30°C to +55°C Working Humidity 10%RH–90%RH (no-condensation) Dimension(W×D×H) 62.0mm×142.0mm×23.0mm Weight 0.5kg Working Environment Outdoor Certificates CE Yes FCC Yes
Основные | |
---|---|
Производитель | Dahua Technology |
Пользовательские характеристики | |
Бренд | Dahua |
- Цена: 33 600 ₸
