System Main Processor Industrial embedded micro-processor Operating System Embedded Linux Operation Interface Web; local GUI Perimeter Protection by Camera Performance 16 channels AI Search Search for pictures by channel, time and event type SMD Plus by Camera Performance 16/32 channels AI Search Search by target classification (human, vehicle) Video Access Channel 16/32 Network Bandwidth 200 Mbps for access, 200 Mbps for storage and 96 Mbps for forwarding Resolution 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more Decoding Capability 8 channels@1080p (30 fps) Video Output HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720VGA: 1920 × 1080; 1280 × 1024; 1280 × 720 Multi-screen Display 16-channel: 1/4/8/9/1632-channel: 1/4/8/9/16/25/36 Third Party Camera Access Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more Compression Video Smart H.265+; Smart H.264+; H.265; H.264 Audio PCM; G.711A; G.711U; G.726 Network Network Protocol HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (supports Dahua IP camera, DVR, NVS, and more); P2P Mobile Phone Access Android; iOS Interoperability ONVIF (profile T/S/G); CGI; SDK Browser Chrome; IE9 or later; Firefox Record Playback Multi-channel Playback 1/4/9/16 Record Mode Manual; schedule (general; MD; alarm; MD & alarm; intelligent) Storage Method Local HDD and network Backup USB device Playback Function 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame2. Full screen; backup (cut/file) ; partially enlarge; audio on/off Storage Disk Group Yes Alarm General Alarm Motion detection; privacy masking; video loss; PIR alarm; IPC alarm Anomaly Alarm Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly Intelligent Alarm Perimeter protection; SMD; people counting; heat map Alarm Linkage Record; snapshot; IPC external alarm output; buzzer; log; preset; email External Port Audio Input 1 channel, RCA connector Audio Output 1 channel, RCA connector, which support voice intercom output HDD 8 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature Alarm Input 16 channels Alarm Output 4 channels RS-232 1 channel, used to debug and pass through serial data RS-485 1 channel, used to control PTZ, and it supports multiple protocols USB 2 front USB 2.0 ports, 1 rear USB 3.0 port HDMI 1 VGA 1 Network 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports General Parameter Power Supply Single, 100V–240V AC, 50 Hz–60 Hz Power Consumption < 12W (without HDD)
Основные | |
---|---|
Производитель | Dahua |
Количество каналов | 32 |
Пользовательские характеристики | |
Бренд | Dahua |
Количество SATA | 8 |
- Цена: 202 100 ₸
