Описание
Характеристики
Информация для заказа
ModelNVR501-04B-LP4NVR501-08B-LP8Video/Audio InputIP Video Input4-ch8-chAudio Input1-ch, RCANetworkIncoming Bandwidth80MbpsOutgoing Bandwidth64MbpsRemote Users128ProtocolsTCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTPBrowserIE(IE10/11) for WindowsFirefox (version 52.0 and above) for WindowsChrome(version 45 and above) for WindowsEdge(version 79 and above) for WindowsVideo/Audio OutputHDMI/VGA OutputHDMI:4K (3840x2160)@30, 1920x1080p@60, 1920x1080p@50, 1600x1200@60, 1280x1024@60, 1280x720@60, 1024x768@60VGA:1920x1080p@60, 1920x1080p@50, 1280x1024@60, 1600x1200@60, 1280x720@60, 1024x768@60Recording Resolution8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIFAudio Output1-ch, RCATwo-way Audio1-ch, RCA(Using the audio input and output)Audio CompressionG.711A, G.711USynchronous Playback4-ch8-chLiveview display1/41/4/6/8/9Corridor Mode Screen3/43/4/5/7/9SnapshotFTP/Schedule/Event Snapshot4-ch snapshot, up to D1 resolutionDecodingDecoding formatUltra 265/H.265Live view/Playback8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIFCapability4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 9 x 4MP@25, 10 x 3MP@30, 16 x 1080p@30Hard DiskSATA1 SATA interfacesCapacityUp to 6TB for each diskSmartVCA Detection by CameraIntrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, SMD(Smart Motion Detection)VCA SearchBehavior Search, People Counting ReportPeople countingPeople Flow Counting, Crowd Density MonitoringSmart Intrusion Prevention (SIP), SMD by CameraTotal 4-chGeneral AlarmGeneral AlarmMotion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio DetectionAlert AlarmIP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot AbnormalExternal InterfaceNetwork Interface1 RJ-45 10M/100M self-adaptive Ethernet InterfaceUSB InterfaceFront panel: 1 x USB2.0, Rear panel: 1 x USB3.0RS232NARS485NAAlarm InNAAlarm OutNAPoEInterface4 RJ-45 10M/100M self-adaptive Ethernet Interface8 RJ-45 10M/100M self-adaptive Ethernet InterfaceMax PowerMax 30W for single portMax 50W in totalMax 30W for single portMax 75W in totalSupported StandardIEEE 802.3af/atGeneralPower Supply48V DC/1.35APower Consumption: ≤ 10W (without HDD)52V DC/1.8APower Consumption: ≤ 10W (without HDD)Working Environment-10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing)Dimensions (W×D×H)205mm × 212mm × 46mm (8.1" × 8.3" × 1.8")Weight (without HDD)≤ 0.98Kg (2.16lb)CertificationCertificationCE, FCC, UL, RoHS, WEEECEEN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017FCCPart15 Subpart B, ANSI C63.4
Основные | |
---|---|
Производитель | Uniview |
Количество каналов | 4 |
Пользовательские характеристики | |
Бренд | Uniview |
Количество PoE каналов | 4 |
Количество SATA | 1 |
- Цена: 51 000 ₸
