SystemMain ProcessorIndustrial-grade processorOperating SystemEmbedded LinuxOperating InterfaceWeb, Local GUIAIAI by RecorderFace detection; face recognition; perimeter protection; SMD PlusAI by CameraFace detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat mapAcuPick AI by Camera + RecorderMax. 16-channel, 1 combined event per channel/sPerimeter ProtectionPerimeter Performance AI by Recorder (Number of Channels)4 channels, 10 IVS rules for each channelPerimeter Performance of AI by Camera (Number of Channels)16 channelsFace DetectionFace AttributesGender; age group; glasses; expressions; face mask; beardFace Detection Performance of AI by Recorder (Number of Channels)2 channels (up to 12 face images/s each channel)Face Detection Performance of AI by Camera (Number of Channels)16 channelsFace RecognitionFace Database CapacityUp to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.Face Recognition Performance of AI by Recorder (Number of Channels)1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s 2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/sFace Recognition Performance of AI by Camera (Number of Channels)16 channelsSMD PlusSMD Plus by Recorder8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition changeSMD Plus by Camera16 channelsVideo MetadataMetadata Performance of AI by Camera (Number of Channels)8 channelsHuman AttributesTop color, top type, bottom color, bottom type, hat, bag, age, gender and umbrellaMotor Vehicle AttributesLicense plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location.Non-motor Vehicle AttributesVehicle model, vehicle color, number of persons, helmet.Vehicle License Plate ComparisonANPR by Camera (Number of Channels)8 channelsLicense Plate Database Capacity1. Create up to 20,000 plate numbers. 2. Blocklist and allowlistAudio and VideoAccess Channel16Network BandwidthAI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoingResolution32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIFDecoding CapabilityAI disabled:2-channel 32 MP@20 fps; 2-channel 24 MP@20 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps;8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps;16-channel 4 MP@30 fps AI enabled:1-channel 32 MP@20 fps; 1-channel 24 MP@20 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fpsVideo Output2 VGA, 2 HDMIVGA:1920 × 1080, 1280 × 1024, 1280 × 720HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720Heterogeneous video source output for HDMI1 and HDMI2 Simultaneous video source output for VGA1 and HDMI1 Simultaneous video source output for VGA2 and HDMI2Multi-screen DisplayMain screen: 1/4/8/9/16 Sub screen: 1/4/8/9/16Third-party Camera AccessONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; SamsungCompression StandardVideo CompressionSmart H.265+; H.265; Smart H.264+; H.264; MJPEGAudio CompressionG.711a; G.711u; PCM; G726NetworkNetwork ProtocolHTTP; HTTPS; TCP/IP; IPv4/IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSIMobile Phone AccessiOS; AndroidInteroperabilityONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDKBrowserChrome;IE;Safari;Edge;FirefoxNetwork ModeMulti-address mode, load balance, fault tolerance and other network port binding modesRecording PlaybackMulti-channel PlaybackUp to 16 channelsRecord ModeGeneral, motion detection; intelligent; alarm; POSBackup MethodUSB device and networkPlayback ModeInstant playback, general playback, event playback, tag playback, smart playback (face and motion detection)StorageDisk GroupYESAlarmGeneral AlarmMotion detection; privacy masking; local alarmAnomaly AlarmCamera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exceptionIntelligent AlarmFace detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat mapAlarm LinkageRecord; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; emailPortAudio Input1-channel RCAAudio Output2-channel RCAAlarm Input16 channelsAlarm Output6 channels (1-channel 12 V 1 A output)HDD Interface4 SATA ports, each disk can contain up to 16 TB. This limit varies depending on the environment temperature.eSATA1RS-2321RS-4851 (half-duplex serial communication)USB3(1 front USB 2.0 port, 2 rear USB 3.0 ports)HDMI2VGA2Network Port2 (10/100/1000 Mbps Ethernet port, RJ-45)GeneralPower Supply100–240 VAC, 50-60 HzPower ConsumptionTotal output of NVR is ≤ 13 W (without HDD)Net Weight4.74 kg (10.45 lb)Gross Weight6.11 kg (13.47 lb)Product Dimensions440.0 mm × 415.1 mm x 70.0 mm (17.32" × 16.34" × 2.76") (W ×D × H)Packaging Dimensions530.0 mm × 500.0 mm × 210.0 mm (20.87" × 19.69" × 8.27")(W × D × H)Operating Temperature–10 °C to +55 °C (14 °F to +131 °F)Storage Temperature–20 °C to +60 °C (–4 °F to +140 °F)Operating Humidity10%–93% (RH)InstallationRack or desktopCertificationsFCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 CE-LVD: EN 62368-1: 2014
Основные | |
---|---|
Производитель | Dahua |
Пользовательские характеристики | |
Количество SATA | 4 |
Количество каналов | 16 |
- Цена: 265 650 ₸
