Описание
Характеристики
Информация для заказа
CameraImage Sensor1/3”4Megapixel progressive CMOSMax. Resolution2560 (H) × 1440 (V)ROM128 MBRAM128 MBScanning SystemProgressiveElectronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 sMin. IlluminationManual 1/30 s 0. 170 Lux @F2.0 (Color, 80 IRE); 0.165 Lux @F2.0 (W/B, 80 IRE); 0 Lux (IR on) Manual 1/3 s 0.0141 Lux @F2.0 (Color, 80 IRE); 0.0116 Lux @F2.0 (W/B, 80 IRE); 0 Lux (IR on)S/N Ratio>46.6 dBIllumination Distance10 m (32.8 ft) (IR LED)Illuminator On/Off ControlAutoIlluminator Number1 (IR LED)Pan/Tilt/Rotation RangePan: 0°–360° Tilt: 0°–90°LensLens TypeFixed-focalMount TypeM12Focal Length2.8 mmMax. ApertureF2.0Field of ViewHorizontal: 97° Vertical: 52° Diagonal: 116°Iris TypeFixedClose Focus Distance0.8 m (2.6 ft)DORI DistanceDetectObserveRecognizeIdentify56.0 m(183.7ft)22.4 m(73.5 ft)11.2 m(36.7 ft)5.6 m(18.4 ft)VideoVideo CompressionH.265; H.264; H.264H; H.264B; MJPEGSmart CodecH.264: Yes H.265: YesVideo Frame Rate50 Hz Main stream (2560 × 1440 @25 fps), sub stream (640 × 480 @25 fps) Main stream (2304 × 1296 @25 fps), sub stream (640 × 360 @25 fps) Main stream (1920 × 1080 @25 fps), sub stream (320 × 240 @25 fps) 60 Hz Main stream (2560 × 1440 @30 fps), sub stream (640 × 480 @30 fps) Main stream (2304 × 1296 @30 fps), sub stream (640 × 360 @30 fps) Main stream (1920 × 1080 @30 fps), sub stream (320 × 240 @30 fps)Stream Capability2 streamsResolution4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); VGA (640 × 480); 640 × 360; QVGA (320 × 240)Bit Rate ControlCBR/VBRVideo Bit RateH.264: 184 kbps–6144 kbps H.265: 73 kbps–6144 kbpsDay/NightAuto (ICR)/Color/B/WBLCYesHLCYesWDRDWDRWhite BalanceAuto/natural/street lamp/outdoor/manual/regional customGain ControlAuto/ManualNoise Reduction3D DNRMotion DetectionOFF/ON (4 areas, rectangular)Region of Interest (RoI)Yes (4 areas)Smart IlluminationYesImage Rotation0°/90°/180°/270°MirrorYesPrivacy Masking4 areasAudioBuilt-in MICYesAudio CompressionAAC; G.711a; G.711MuAlarmAlarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tamperingNetworkNetworkRJ-45 (10/100 Base-T)SDK and APIYesProtocolHTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6; QoS; NTPInteroperabilityONVIF (Profile T/Profile S/Profile G); CGI; DMSSUser/Host20 (Total bandwidth: 100 M)StorageNAS; FTP; SFTP; Micro SD card (256 G)BrowserIE: IE7 and later Chrome: Chrome 45 and later Firefox: FireFox 46 and later Safari: Mac os Safari12Management SoftwareDMSSMobile PhoneIOS; AndroidMobile PhoneIOS; AndroidCertificationCertificationCE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart BPortAlarm Input1 channel in: 5mA 3V~5V DCAlarm Output1 channel out: 300mA 12V DCPowerPower Supply12V DC/PoEPower ConsumptionMax 3.3W (12V DC)EnvironmentOperating Conditions–10°C to +45°C (14°F to +113°F)/Less than 95%RHStorage Conditions–40°C to +60°C (–40°F to +140°F)StructureCasingPlasticDimensionsΦ78.5 mm × 90.5 mm × 127.8 mm (3.1" × 3.6" × 5.0") (L × W × H)Net Weight170 g (0.4 lb)Gross Weight270 g (0.6 lb)
Основные атрибуты | |
---|---|
Производитель | Dahua |
Объектив | |
Тип объектива | Фиксированный |
Пользовательские характеристики | |
Бренд | Dahua |
Дальность ИК-подсветки | 10 м |
исполнение | Внутреннее |
Материал корпуса | Пластик |
Наличие MicroSD | Да |
Наличие микрофона | Да |
Объектив | 2.8 мм |
Рабочая температура | -10°C до +45°C |
Разрешение | 4 мп |
- Цена: 9 999 999 ₸
