Описание
Характеристики
Информация для заказа
CameraImage Sensor1/2.7" CMOSMax. Resolution3840 (H) × 2160 (V)ROM128 MBRAM256 MBScanning SystemProgressiveElectronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 sMin. Illumination0.008 lux@F1.5 (Color, 30 IRE) 0.0008 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on)S/N Ratio>56 dBIllumination Distance40 m (131.23 ft) (IR)Illuminator On/Off ControlAuto; ManualIlluminator Number2 (IR LED)Pan/Tilt/Rotation RangePan: 0°–355° Tilt: 0°–67° Rotation: 0°–355°LensLens TypeMotorized vari-focalLens Mountφ14Focal Length2.7 mm–13.5 mmMax. ApertureF1.5Field of ViewH: 113°–31°; V: 58°–18°; D: 138°–36°Iris ControlFixedClose Focus Distance0.8 m (2.62 ft)DORI DistanceLensDetectObserveRecognizeIdentifyW85.3 m (279.86 ft)34.1 m(111.88 ft)17.1 m(56.10 ft)8.5 m(27.89 ft)T280.0 m (918.64 ft)112.0 m(367.45 ft)56.0 m(183.73 ft)28.0 m(97.86 ft)IntelligenceIVS (Perimeter Protection)Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)Smart SearchWork together with Smart NVR to perform refine intelligent search, event extraction and merging to event videosVideoVideo CompressionH.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)Smart CodecSmart H.265+; Smart H.264+Video Frame RateMain stream: 3840 × 2160@(1–20 fps)/2688 × 1520@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Stream Capability2 streamsResolution3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 × 1728 (3072 × 1728); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)Bit Rate ControlCBR/VBRVideo Bit RateH.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbpsDay/NightAuto(ICR)/Color/B/WBLCYesHLCYesWDR120 dBWhite BalanceAuto; natural; street lamp; outdoor; manual; regional customGain ControlAuto;ManualNoise Reduction3D NRMotion DetectionOFF/ON (4 areas, rectangular)Region of Interest (RoI)Yes (4 areas)Smart IlluminationYesImage Rotation0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)MirrorYesPrivacy Masking4 areasAudioBuilt-in MICYesAudio CompressionG.711a; G.711Mu; PCM; G.726AlarmAlarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; defocus detection; external alarm (Only - ZAS supports); SMD; security exceptionNetworkNetwork PortRJ-45 (10/100 Base-T)SDK and APIYesNetwork ProtocolIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; BoujourInteroperabilityONVIF (Profile S/Profile G/Profile T); CGI; P2P; MilestoneUser/Host20 (Total bandwidth: 48 M)StorageFTP; SFTP; Micro SD card (support max. 256 GB); NASBrowserIE; Chrome; FirefoxManagement SoftwareSmart PSS; DSS; DMSSMobile ClientiOS; AndroidCyber SecurityConfiguration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certificationCertificationCertificationsCE-LVD: EN62368-1;CE-EMC: Electromagnetic Compatibility Directive2014/30/EU;FCC: 47 CFR FCC Part 15, Subpart B;UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14PortAudio Input1 channel (RCA port) (Only - ZAS supports)Audio Output1 channel (RCA port) (Only - ZAS supports)Alarm Input1 channel in: 5mA 3V–5 VDC (Only - ZAS supports)Alarm Output1 channel out: 300mA 12 VDC (Only - ZAS supports)PowerPower Supply12 VDC/PoE (802.3af)Power Consumption-ZS: Basic: 2.7 W (12 VDC); 3.4 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 6.3 W (12 VDC); 7.2 W (PoE) -ZAS: Basic: 2.7 W (12 VDC); 3.4 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 6.4 W (12 VDC); 7.3 W (PoE)EnvironmentOperating Temperature–30 °C to +60 °C (–22 °F to +140 °F)Operating Humidity≤95%Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)Storage Humidity≤95%ProtectionIP67; IK10StructureCasing MaterialMetalProduct Dimensions93.4 mm × Φ122 mm (3.68" × Φ4.80")Net Weight-ZS: 0.50 kg (1.10 lb) -ZAS: 0.51 kg (1.12 lb)Gross Weight-ZS: 0.66 kg (1.46 lb) -ZAS: 0.67 kg (1.48 lb)
Основные | |
---|---|
Производитель | Dahua |
Пользовательские характеристики | |
Дальность ИК-подсветки | 40 м |
исполнение | Внутреннее |
Материал корпуса | Металл |
Наличие MicroSD | Да |
Наличие микрофона | Да |
Объектив | 2.7-13.5 мм |
Рабочая температура | -30°C до +60°C |
Разрешение | 8 мп |
Тип объектива | Вариофокальный |
- Цена: 126 500 ₸
