Описание
Характеристики
Информация для заказа
CameraImage Sensor1/2.8" CMOSMax. Resolution1920 (H) × 1080 (V)ROM128 MBRAM128 MBScanning SystemProgressiveElectronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 sMin. Illumination0.002 lux@F1.6 (Color, 30 IRE) 0.0002 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on)S/N Ratio>56 dBIllumination Distance30 m (98.43 ft) (IR), 30 m (98.43 ft) (Warm light)Illuminator On/Off ControlAuto; ManualIlluminator Number1 (IR LED); 1 (Warm light)Pan/Tilt/Rotation RangePan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°LensLens TypeFixed-focalLens MountM12Focal Length2.8 mm; 3.6 mmMax. ApertureF1.6Field of View2.8 mm: H: 107°; V: 56°; D: 127°;3.6 mm: H: 88°; V: 44°; D: 105°Iris ControlFixedClose Focus Distance2.8 mm: 0.7 m (2.30 ft);3.6 mm: 1.3 m (4.27 ft)DORI DistanceLensDetectObserveRecognizeIdentify2.8 mm43.9 m(144.03 ft)17.5 m(57.41 ft)8.8 m(28.87 ft)4.4 m(14.44 ft)3.6 mm58.9 m(193.24 ft)23.6 m(77.43 ft)11.8 m(38.71 ft)5.9 m(19.35 ft)IntelligenceIVS (Perimeter Protection)Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)Smart SearchWork together with Smart NVR to perform refine intelligent search, event extraction and merging to event videosVideoVideo CompressionH.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)Smart CodecSmart H.265+; Smart H.264+Video Frame RateMain stream: 1920 × 1080@ (1–25/30 fps) Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.Stream Capability2 streamsResolution1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)Bit Rate ControlCBR/VBRVideo Bit RateH.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbpsDay/NightAuto (ICR)/Color/B/WBLCYesHLCYesWDR120 dBWhite BalanceAuto; natural; street lamp; outdoor; manual; regional customGain ControlAuto; ManualNoise Reduction3D NRMotion DetectionOFF/ON (4 areas, rectangular)Region of Interest (RoI)Yes (4 areas)Smart IlluminationYesImage Rotation0°/90°/180°/270° (Support with 1080p resolution and lower)MirrorYesPrivacy Masking4 areasAudioBuilt-in MICYesAudio CompressionG.711a; G.711Mu; PCM; G.726AlarmAlarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; SMD; voltage detection; security exceptionNetworkNetwork PortRJ-45 (10/100 Base-T)SDK and APIYesNetwork ProtocolIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMPInteroperabilityONVIF (Profile S/Profile T); CGI; P2P; MilestoneUser/Host6 (Total bandwidth: 36 M)StorageFTP; SFTP; Micro SD card (support max. 256 GB)BrowserIE; Chrome; FirefoxManagement SoftwareDSS; DMSSMobile ClientiOS; AndroidCyber SecurityConfiguration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certificationCertificationCertificationsCE-LVD: EN 62368-1CE-EMC: Electromagnetic Compatibility Directive 2014/30/EUFCC: 47 CFR FCC Part 15, Subpart BPowerPower Supply12 VDC/PoE (802.3af)Power ConsumptionBasic: 1.6 W (12 VDC); 1.9 W (PoE); Max. (H.265 + intelligence + WDR + warm light): 3.8 W (12 VDC); 4.4 W (PoE)EnvironmentOperating Temperature–40 °C to +60 °C (–40 °F to +140 °F)Operating Humidity≤95%Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)ProtectionIP67StructureCasing MaterialMetalProduct Dimensions166.2 mm × 70 mm × 70 mm (6.54" × 2.76" × 2.76") (L × W × H)Net Weight0.48 kg (1.06 lb)Gross Weight0.59 kg (1.30 lb)
Основные | |
---|---|
Производитель | Dahua |
Пользовательские характеристики | |
LED подсветка | 30 м |
Дальность ИК-подсветки | 30 м |
исполнение | Уличное |
Материал корпуса | Металл |
Наличие MicroSD | Да |
Наличие микрофона | Да |
Объектив | 2.8 мм |
Рабочая температура | -40°C до +60°C |
Разрешение | 2 мп |
Тип объектива | Фиксированный |
- Цена: 42 550 ₸
