Model UAC-B115-AF28-W UAC-B115-AF40-W SensorPixel5MPSize1/2.7"Minimum illumination0.01 lux (F1.6, AGC ON)0 lux (white light on)LensLens2.8mm4.0mmLens mountM12Angle of view H: 110.0° V: 57.0° D: 130.0°H: 90.0° V: 48.0° D: 109.1°IlluminatorIlluminatorOne white-light illuminatorIllumination distance20mLifetime≥60,000 hoursVideoResolution5MP@25fps: 2880(H)×1620(V); 5MP@20fps: 2592(H)×1944(V); 5MP@12.5fps: 2592(H)×1944(V)4MP: 2560(H)×1440(V)1080P: 1920(H)×1080(V)Frame rateTVI: 5MP@20fps (default), 5MP@12.5fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fpsAHD: 5MP@20fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fpsCVI: 5MP@25fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fpsCVBS: PAL, NTSCShutter timePAL: 1/25s-1/50000sNTSC: 1/30s–1/50000sImageExposure modeFour modes: Global (default), BLC, HLC, DWDR Day/Night24/7 color imagesDigital noise reduction2DWhite balanceTwo modes: Auto (default), ManualWDRDWDRFlipSupports 180° horizontal flip, 180° vertical flipDefogN/A AudioMicrophone Built-in MicCamera audio TVI: 5MP@20fps, 5MP@12.5fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fpsCVI: 5MP@25fps, 4MP@25fps, 4MP@30fpsInterfacePower5.5mm power interfaceVideo outputBNC, supports TVI/AHD/CVI/CVBSOperating environmentTemperature-30℃ to 60℃(-22℉ to 140℉)Humidity≤95% (RH, non-condensing)Surge protection4KVGeneralPowerDC 12V(±25%), with reverse polarity protection, Max 2.3WMountSurface mount (default), optional backbox, pole mount bracketDimensions142mm*63mm*65mm (L*W*H)MaterialGraphene+PlasticWeight150g (0.33lb)OSD menu language11 LanguagesEnglish, German, Spanish(Latin America), French, Italian, Japanese, Korean, Polish, Portuguese(Brazil), Russian, TurkishCertificationEMCCE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035)FCC (FCC 47 CFR part15 B)SafetyCE-LVD (EN 62368-1)EnvironmentCE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)ProtectionIP67 (IEC 60529)
Основные | |
---|---|
Производитель | Uniview |
Пользовательские характеристики | |
LED подсветка | 20 м |
Наличие MicroSD | Нет |
Наличие микрофона | Да |
Объектив | 2.8 мм |
Рабочая температура | -30°C to 60°C |
Разрешение | 5 мп |
Тип объектива | Фиксированный |
- Цена: 11 000 ₸
